Wooden Crate

€9.09

Tax included

Wooden crate in customizable sizes (lenght, width and hight) and strenght (small, medium, large, extra).

Quantity

	Min.	Max.
Inner usefull width	20cm	150cm
Inner usefull height	10cm	210cm
Inner usefull length	20cm	490cm

2 question about the product

Payment by credit card, Paypal, Apple Pay, Google Pay, Bitcoin, bank transfer.
Shipping throughout Europe with delivery times indicated when ordering.
Returns possible under certain conditions, read the general terms and conditions of this link

Description
Product Details

Wooden crate customisable in dimensions (length, width and hight) and strength (small, medium, large, extra), possibility of ispm15 fao treatment for exportation and any indelible black ink markings with a maximum of 45 characters. The pallet can also be realized in a planed version, suitable for furnishing. We produce all wooden crate we sell.

Reference W-GBAS

In stock 9999989 Items

Product customization:

click here for guidance on how to order.

How to insert the measures properly:

*The image refers to the wooden box.
Attention: the inserted measurements are INTERNAL measurements and are expressed in centimeters, in the note of every product are indicated the cm to be added to get the EXTERNAL measurements.

Enter here the quantity:

Quantity:

(An order of 2 pieces has a discount of 2% - of 5 pieces of 5% - of 10 pieces of 7% - of 50 pieces of 10% - of 100 pieces of 12% - of 200 pieces of 15% - of 500 pieces of 20% - depending on the measures)

Enter here the length:

Inner usefull length cm

(Measure must be expressed in cm - min 20cm/max 490cm)

Enter here the width:

Inner usefull width cm

(Measure must be expressed in cm - min 20cm/max 150cm)

Enter here the height:

Inner usefull height cm

(Measure must be expressed in cm - min 10cm/max 210cm)

Strength:

Section of the used material - strenght of the box.

Medium
Large
Extra

Assembled:

Completely finished or with only the six sides preassembled.

Assembled
Not assembled (The assembly is done by the customer)

Warning: If you select "not assembled", the assembly is carried by the customer!

Forklift ready:

Bottom with a pallet below or not.

Forklift ready
Not forklift ready

Planed boards:

Select if boards must be planed or not (recommended for furnishing).

Not planed
Planed

Galvanized nails:

Select if nails must be galvanized or not (recommended for furnishing).

Not galvanized
Galvanized

Marking:

Select if boards must be marked or not.

Product measures
Personalised
No markings

Marking Text:

Input the marking text (max 45 characters - special characters are not allowed).

ISPM15:

ISPM15 heat sterilization treatment for exportation to non-EU.

Not treated
Treated

Config Description

Weight:: Kg

Add to Cart

Main manufacturing characteristics:

- Type of material:

- The wooden crates are made of European dried fir wood (humidity max 20%);
- Medium version: all boards 9,5x1,5cm;
- Large version: all boards 9,5x1,8cm;
- Extra version: all boards 12x2,2cm;
- Extra version - planed: all boards 11,5x1,8cm;
- Planed option is limited to the extra version;

- Size limitations:

- Minimum size: 20cmx20x10h;
- Medium version: max 150cmx120x210h;
- Large version: max 350cmx120x210h;
- Large if width > 70cm - max lenght 200cm;
- Extra: max 490x150x210hcm;
- Extra if width > 100cm - max lenght 290;

- Cm to be added to the inserted measures to obtain the external measures of the box:

- Medium version: lenght 6cm - width 6cm - height 13,2cm (if not pallettized height cm 6cm);
- Large version: lenght 7cm - width 7cm - height 15cm (if not pallettized height 7cm);
- Extra version: lenght 9cm - width 9cm - height 16cm (if not pallettized height 9cm);
- Version extra-planed: lenght 7cm - width 7cm - height 15cm (if not pallettized height 7cm);

- Indicative weight for model 120cmx80x80h:

- Medium: 35kg;
- Large: 40kg;
- Extra: 60kg;
- Extra-planed:40kg;

- Indicative static/dynamic carrying capacity for 120x80cm model:

- Medium version: 500 / 300kg;
- Large version: 800 / 500kg;
- Extra version: 2000 / 1000kg;
- Crates are to be considered not stackable and not superimposeable;
- The dimensions increase involves a decrease more than proportional of the carrying capacity;
- The relative structural rigidity of the contained material, as for example the presence of a bearing metal skid below the product, can also increase considerably the effective range of the carrying capacity;

- ISPM15 treatment for export:

- The treatment is required to export to non-EU countries;
- The treatment consists in an oven high temperature sterilization;
- The price includes sterilization, markings and documentation stating the treatment;

- Pallet marking:

- Marking by inkjet printing with indelible black ink;
- Maximum 45 characters;
- The wording is not available for sizes smaller than 50cm.

Passa al listino industria

Solo prodotti destinati all'imballo, partita iva, prezzo netto, ordine minimo di 300 Euro

VIDEO

Questions

Send us your question

Adriana Grossi on 2017-04-25 14:41:45	Question: Dovrei spedire un tavolo smontato in Inghilterra, avrei bisogno di una gabbia o cassa ? Il prodotto deve essere ispezionabile all interno , voi prevedete questo? Grazie Adriana
	Answer: Se il tavolo è grosso le consiglio la cassa travata (la base è portante) altrimenti possono andare bene anche la gabbia e la cassa classici (senza base travata).https://www.imballoinlegno.it/it/casse-in-legno/6-cassa-in-legno.htmlhttps://www.imballoinlegno.it/it/casse-in-legno/7-cassa-in-legno-osb.htmlhttps://www.imballoinlegno.it/it/casse-in-legno/10-cassa-legno-travata.htmlhttps://www.imballoinlegno.it/it/gabbie-in-legno/9-gabbia-in-legno.html Nel caso delle casse se vuole che l'interno sia ispezionabile possiamo applicare 1 o 2 sportelli di ispezione doganale (dimensione circa 15x15cm). Hanno un costo di 15 euro l'uno e non le trova sul sito. Nel caso lo indica nelle note durante la chiusura dell'ordine. La gabbia ha spazi vuoti tra tavola e tavola di circa 25/30cm x 25/30cm. Per ogni altro dubbio non esiti a contattarci.

Arianna Bayre on 2017-03-30 17:06:31	Question: Buonasera . Vorrei ordinare una cassa per uso arredamento . Nello specifico vorrei una struttura di larghezza 120 , altezza 120 e lunghezza 220cm . Dovrebbe essere una cassa con parte superiore ed inferiore piatta con lo scopo di appoggiarci sopra un materasso singolo . L'ideale sarebbe creare frontalmente una apertura o meglio più aperture per usare la sua profondità come un " ripostiglio ". Pallet piccoli per creare una scaletta di salita . Sapreste aiutarmi ? È possibile ? Grazie mille
	Answer: Una possibile soluzione potrebbe essere la cassa travata: https://www.imballoinlegno.it/it/casse-in-legno/10-cassa-legno-travata.html con opzione senza base e indicando nelle note dell'ordine "con coperchio invertito (listelli interni)". Andrebbe poi aggiunta una piccola travatura lungo la fiancata in modo che lei possa poi levare/tagliare/modificare la fiancata per ricavarci le aperture di cui ha bisogno. Per il pallet da usare come scaletta potrebbe usare pallet a 2 vie https://www.imballoinlegno.it/it/pallets-in-legno/1-pallet-a-2-vie.html messi in verticale sul moraletto di diversa lunghezza. Visto che è per arredamento le consigliamo di scegliere la versione piallata/chiodi zincati.
